Android Touch Screen Smart Handheld Terminal POS

High Speed All In One Wireless NFC Smart Handheld Android POS Terminal with Printer

5.0'' HD, 1280*720 IPS; G+FF capacitive multi touch screen

Compact design for better mobility

Product Details

Mobile Portabel Handheld Smart POS Terminal:

1.  Tablet configuration:  1.3GHz Quad-core CPU which supports the simultaneous operation of multiple utility easily. Android 7.1 Naugat OS with high compatibility and stability.

2. Screen:  5”HD+, 1280*720 IPS, capacitive multi-touch panel.

3. Built-in Printer:  58mm direct thermal printing, support roll diameter 40mm.

4. Built-in MSR(Optional):  Magnetic stripe card supported

5. Embedded NFC (Optional):  Contactless IC card supported.

6. QR code scanning head (Optional):  Includes decoder chip of QR code, support all barcodes types and common QR code.

7. Camera:  5.0MP, AF, rear-facing camera for scanning various barcodes and QR code, and it’s available for scanning payment code such as WeChat, Alipay etc.


Specification

Introduction

R330 Smart Handheld POS Terminal

Processor

Snapdragon 425, 1.4GHz, Quad-core, Cortex-A53

Memory

1GB RAM, 8GB Flash, ( 2+16 optional )

OS

Android 7.1 Nougat

Display

5.0'' HD, 1280*720 IPS; G+FF multi-capacitive touch

Key PAD

Power on / off, Volume up / Scanner

Card Slot Support

SIM: 1*SIM Card ( 1.8v / 3.0 v )

Fiscal Module

Support 12C or UART interface 30.0±0.2*30.0±0.2*9.2±0.2 mm

Data Connect

Communication: GSM, WCDMA, TDD_LTE, FDD_LTE

NFC: ISO/ICE 14443 Type A & B, Mifare card at optional

WIFI: 2.4G/5GHz,Support IEEE802.11a/b/g/n

Bluetooth: Support 2.1/3.0/4.0, BLE, ibeacon

GPS

Built-in GPS, support A-GPS

Termal Printer

High-speed 58mm line, 40 mm Roll, low noise, power saving

Camera

Rear Camera: 5.0 M, AF (automatic focus)



Front Camera: 0.3 M 3P, FF (Fixed-focus)

Barcode Scanner

Built-in 1D barcode scanning modules, 2D QR code is optional

Battery

Two 18650 cell from samsung ( ICR 18650-26J ) 7.4v / 2600 mAh

Speaker

0.8 W / 85 dB

Earphone-jack

3.5mm standard, support external RFID reader via this connector

Interface

1*Micro USB connector, support OTG USB to RJ45 network

Adaptor

Input: AC 100~240v, 0.5 A, output: 5v / 2 A

Dimensions

198*79*48 (L*W*H) mm

Anti-Drop

1.2 meter

Environment

Normal Operating Temperature: 0-40℃

Storage Temperature: -20℃ ---60℃
