Inch Touch Screen NFC 4G Android Handheld POS System with Thermal Printer R330
In line with the mobile, intelligent and contactless payment trends of global service industry, the R series smart pos came into being. Featureing the latest Android system, leading hardware configuration, helps customers to serve rapidly growing & comprehensive business needs. In addition, for customers' tough outdoor and general indoor application scenarios, and business scenarios with and without bank cards, the R series products provide customers various dedicated smart & reliable platforms with cutting-edge design.
Feature
Specification
|
Introduction |
R330 Smart Handheld POS Terminal |
|
Processor |
Snapdragon 425, 1.4GHz, Quad-core, Cortex-A53 |
|
Memory |
2GB RAM,16GB Flash |
|
OS |
Android 7.1 |
|
Display |
5.0'' HD, 1280*720 IPS; G+FF multi-capacitive touch |
|
Key PAD |
Power on / off, Volume up / Scanner |
|
Card Slot Support |
SIM: 1*SIM Card ( 1.8v / 3.0 v ) |
|
Fiscal Module |
Support 12C or UART interface 30.0±0.2*30.0±0.2*9.2±0.2 mm |
|
Data Connect |
Communication:4G(Full band)/3G/2G |
|
|
WIFI: 2.4G/5GHz、Support IEEE802.11a/b/g/n |
|
|
Bluetooth: Support 3.0/4.0, BLE, ibeacon |
|
GPS |
Built-in GPS, support A-GPS |
|
Thermal Printer |
High-speed 58mm line, 40 mm Roll, low noise, power saving |
|
Camera |
Rear Camera: 5.0 M, AF (automatic focus) |
|
|
Front Camera(Optional): 0.3 M 3P, FF (Fixed-focus) |
|
Battery |
Two 18650 cell from samsung ( ICR 18650-26J ) 7.4v / 2600 mAh |
|
Speaker |
0.8 W / 85 dB |
|
Earphone-jack |
3.5mm standard, support external RFID reader via this connector |
|
Interface |
1*Micro USB connector, support OTG USB to RJ45 network |
|
Adaptor |
Input: AC 100~240v, 0.5 A, output: 5v / 2 A |
|
Dimensions |
198*79*48 (L*W*H) mm |
|
Anti-Drop |
1.2 meter |
|
Certification |
CE, ROHS |
|
Optional |
NFC: ISO/ICE14443, Type A/B, Mifare Card |
|
|
Support 1D CCD barcode scanning and reading |
