the most cost-effective handheld scanner with fast scanning and damage barcode reading ability. OEM project or ODM project with private logo is acceptable with the MOQ requirement.
the most cost-effective handheld scanner with fast scanning and damage barcode reading ability. OEM project or ODM project with private logo is acceptable with the MOQ requirement.
Product Information:
Model: HN-3308SR Wireless handheld scanner manufacturer
Product Features：
Product Advantages:
High Performance on decoding technology
Compared with low-end scanners, HN-3308SR bluetooth handheld scannerstands out in decoing speed and accuracy. The scan engine read both 1D and 2D even for moving barcode with a powerful imager scanning.
Highly versatile
Extended depth of field: scans out-of-reach items with ease and allows users to scan barcodes from as far as 15.7inches/400mm, and reads high density barcodes as small as 3mil.
Agressive scan performance
HN-3308SR Wireless handheld scanner maintain productivity with a worry-free liner scannning solution even when reading damaged and distorted barcodes eliminates wasted times from every transaction.
Different keyboard languages
Our handheld 2d barcode scanner supports more than 80 countries keyboard language output.
Class-leading durability
Android handheld barcode scanner is with 1.5M drop resistance.
Fully compatible with all kinds of systems
Windows, IOS, Android, Linux, as professtional wireless scanner manufactuers, iDPRT's barcode scanner series allows ease of use with quick plug & play interfaces.
Product Specification:
| Model | HN-3308SR | HN-3358SR | HN-3378SR |
| Symbologies | 1D/2D | 1D/2D | 1D/2D |
| Image Sensor | CMOS | CMOS | CMOS |
| Pixel | 640*480【GS】 | 640*480【GS】 | 640*480【GS】 |
| Resolution | ≥3mil | ≥3mil | ≥3mil |
| FOV | Horizontal: 40 °, Vertical: 30 ° | Horizontal: 40 °, Vertical: 30 ° | Horizontal: 40 °, Vertical: 30 ° |
| DOF |
5mil Code39： 20mm–170mm 13mil ENA： 30mm–350mm 6.7mil PDF417： 25mm–150mm 10mil DM： 15mm–120mm 20mil QR： 15mm–210mm |
5mil Code39： 20mm–170mm 13mil ENA： 30mm–350mm 6.7mil PDF417： 25mm–150mm 10mil DM： 15mm–120mm 20mil QR： 15mm–210mm |
5mil Code39： 20mm–170mm 13mil ENA： 30mm–350mm 6.7mil PDF417： 25mm–150mm 10mil DM： 15mm–120mm 20mil QR： 15mm–210mm |
| Interface | USB | USB/Bluetooth | USB/Bluetooth |
| Radio Technology | NA | Bluetooth 5.0 | Bluetooth 5.0 |
| Communication Distance | 10m (in open space) | 100m (in open space) | |
| Memory Capacity | capable of storing the data of over 8000 EAN-13 barcodes | capable of storing the data of over 100,000 EAN-13 barcodes | |
| Battery | 2600mAh lithium-ion battery | 2600mAh lithium-ion battery | |
| Expected Battery Life |
≥12 hours (scan once per 1 seconds) |
≥12 hours (scan once per 1 seconds) |
|
| Expected Charge Time | ≤6 hours (with power adapter) | ≤6 hours (with power adapter) | |
| Charge Interface | USB Type-C | USB Type-C/Charging Cradle | |
| ESD |
±15 kV Air Discharge， ±8 kV Direct Discharge |
±15 kV Air Discharge， ±8 kV Direct Discharge |
±15 kV Air Discharge， ±8 kV Direct Discharge |
| IP Rating | IP42 | IP42 | IP42 |
| Drop | 1.5m | 1.5m | 1.5m |
| Certifications | CE/FCC/ROSH | CE/FCC/ROSH | CE/FCC/ROSH |
| Dimension(mm) | 93(L)*66(W)*166(H) | 93(L)*66(W)*166(H) | 93(L)*66(W)*166(H) |
| Weight | 138g | 171g | 171g |
Product Overview：
