“The World's First Single-Phase Microinverter”designed for 4 solar panels with dual MPPT, with wide
DC input operating voltage range (16-60V) and low start-up voltage (22V only)
Warranty :
10years/25years(optional)Certificate :
TUV,UL,IEC,CE,SGSGreystone solar power microinverter for Grid-Tie Solar System
Product Details
|
Item |
Description
|
|
A |
AC End Cable (Female), 2m 12AWG Cable |
| B |
M8*25 screws |
| C |
DC Extension Cable, 1m |
| D |
|
|
All accessories above are not included in the package, and need to be purchased
separately. Please contact our sales representative for the price. (M8 screws need to be
prepared by installer-self.
|
|
Technical Parameter
| Model | |||
| Input Data(DC) | |||
| Commonly used module power(W) |
240-310 |
||
| Module cmpatibility |
60 cells or 72 cells PV modules |
||
| Peak power MPPT voltage range(V) |
27-48 |
||
| Start-up voltage(V) |
22 |
||
| Operating voltage range(V) |
16-60 |
||
| Maximum input voltage(V) | 60 | ||
| Maximum input current(V) |
4*10.5 |
||
| Output Data(AC) | |||
| Rated output power(W) | 1000 | ||
| Nominal output voltage(A) | 240/211-264 | ||
|
Nominal output voltage range(V) |
180-275 | ||
| Nominal frequency/range(Hz) | 60/55-65 | ||
| Power factor | >0.99 | ||
| Total harmonic distortion | <3% | ||
| Maximum units per branch | 4/3 | ||
| Efficiency | |||
| CEC peak efficiency | 96.7% | ||
| CEC weighted efficiency | 96.5% | ||
| Nominal MPPT efficiency | 99.8% | ||
| Nighttime power consumption(mW) | <50 | ||
| Mechanical Data | |||
| Ambient temerature range (℃） | -40~+65 | ||
| Dimensions (WxHxD mm) | 280x176x33 | ||
| Weight (KG) | 3.75(including 2.32m AC cable) | ||
| Enclosure rating | Outdoor-IP67 | ||
| Cooling | Natural convection-No fans | ||
| Features | |||
| Communication |
2. 4GHz Proprietary RF(Nordic) |
||
| Monitoring | Monitoring system | ||
| Warranty | Up to 25 years | ||
| Compliance |
UL1741,IEEE1547, CSA C22.2 No. 107.1-16, FCC 15C,FCC 15B |
||
2.The solar panels do not interfere with each other, independent power generation has no short-board effect.The system efficiency can be maximized
3.In the environment with shadow obscuration,it can shows more efficient conversion efficiency than ordinary on grid string inverters.
