TP-SUCP Thermoplastic Pillow blocks,Solid base housing,Stainless steel inserts,With food grade grease and silicon rubber seal,Setscrew locking
TP-SUCP Thermoplastic Pillow blocks,Solid base housing,Stainless steel inserts,With food grade grease and silicon rubber seal,Setscrew locking
Unit No.
Shaft Dia
Dimensions(mm)
Bolt Size (mm)
Weight (kg)
d
H
L
J
A
N
N1
H1
Ho
B
S
(in)
(mm)
TP-SUCP201
12
33.3
127
95
38
11
14
15
65.5
31
12.7
M10
0.29
TP-SUCP201-8
1/2
33.3
127
95
38
11
14
15
65.5
31
12.7
M10
0.29
TP-SUCP202
15
33.3
127
95
38
11
14
15
65.5
31
12.7
M10
0.29
TP-SUCP202-9
9/16
33.3
127
95
38
11
14
15
65.5
31
12.7
M10
0.29
TP-SUCP202-10
5/8
33.3
127
95
38
11
14
15
65.5
31
12.7
M10
0.29
TP-SUCP203
17
33.3
127
95
38
11
14
15
65.5
31
12.7
M10
0.29
TP-SUCP203-11
11/16
33.3
127
95
38
11
14
15
65.5
31
12.7
M10
0.29
TP-SUCP204
20
33.3
127
95
38
11
14
15
65.5
31
12.7
M10
0.29
TP-SUCP204-12
3/4
33.3
127
95
38
11
14
15
65.5
31
12.7
M10
0.29
TP-SUCP205
25
36.5
140
105
38
11
14
16
71
34.1
14.3
M10
0.32
TP-SUCP205-14
7/8
36.5
140
105
38
11
14
16
71
34.1
14.3
M10
0.32
TP-SUCP205-15
15/16
36.5
140
105
38
11
14
16
71
34.1
14.3
M10
0.32
TP-SUCP205-16
1
36.5
140
105
38
11
14
16
71
34.1
14.3
M10
0.32
TP-SUCP206
30
42.9
163
119
46
14
18
18
84
38.1
15.9
M12
0.58
TP-SUCP206-17
1-1/16
42.9
163
119
46
14
18
18
84
38.1
15.9
M12
0.58
TP-SUCP206-18
1-1/8
42.9
163
119
46
14
18
18
84
38.1
15.9
M12
0.58
TP-SUCP206-19
1-3/16
42.9
163
119
46
14
18
18
84
38.1
15.9
M12
0.58
TP-SUCP206-20
1-1/4
42.9
163
119
46
14
18
18
84
38.1
15.9
M12
0.58
TP-SUCP207
35
47.6
168
127
48
14
18
18
94.5
42.9
17.5
M12
0.76
TP-SUCP207-20
1-1/4
47.6
168
127
48
14
18
18
94.5
42.9
17.5
M12
0.76
TP-SUCP207-21
1-5/16
47.6
168
127
48
14
18
18
94.5
42.9
17.5
M12
0.76
TP-SUCP207-22
1-3/8
47.6
168
127
48
14
18
18
94.5
42.9
17.5
M12
0.76
TP-SUCP207-23
1-7/16
47.6
168
127
48
14
18
18
94.5
42.9
17.5
M12
0.76
TP-SUCP208
40
49.2
184
137
54
14
18
19.5
99
49.2
19
M12
0.97
TP-SUCP208-24
1-1/2
49.2
184
137
54
14
18
19.5
99
49.2
19
M12
0.97
TP-SUCP208-25
1-9/16
49.2
184
137
54
14
18
19.5
99
49.2
19
M12
0.97
TP-SUCP209
45
54
192
146
54
17
20
23
106
49.2
19
M16
1.08
TP-SUCP209-26
1-5/8
54
192
146
54
17
20
23
106
49.2
19
M16
1.08
TP-SUCP209-27
1-11/16
54
192
146
54
17
20
23
106
49.2
19
M16
1.08
TP-SUCP209-28
1-3/4
54
192
146
54
17
20
23
106
49.2
19
M16
1.08
TP-SUCP210
50
57.2
206
159
60
17
20
24
114
51.6
19
M16
1.24
TP-SUCP210-30
1-7/8
57.2
206
159
60
17
20
24
114
51.6
19
M16
1.24
TP-SUCP210-31
1-15/16
57.2
206
159
60
17
20
24
114
51.6
19
M16
1.24
TP-SUCP210-32
2
57.2
206
159
60
17
20
24
114
51.6
19
M16
1.24
TP-SUCP211
55
63.5
217
172
60
17
20
22
124
55.6
22.2
M16
1.6
TP-SUCP211-32
2
63.5
217
172
60
17
20
22
124
55.6
22.2
M16
1.6
TP-SUCP211-34
2-1/8
63.5
217
172
60
17
20
22
124
55.6
22.2
M16
1.6
TP-SUCP211-35
2-3/16
63.5
217
172
60
17
20
22
124
55.6
22.2
M16
1.6
TP-SUCP212
60
69.9
238
186
66
18
24
24
137
65.1
25.4
M16
2.4
TP-SUCP212-36
2-1/4
69.9
238
186
66
18
24
24
137
65.1
25.4
M16
2.4
TP-SUCP212-38
2-3/8
69.9
238
186
66
18
24
24
137
65.1
25.4
M16
2.4
TP-SUCP212-39
2-7/16
69.9
238
186
66
18
24
24
137
65.1
25.4
M16
2.4
