The Tenlog TL-D5 Dual Filament 3D Printer brings a large building volume 500*mm*500mm*600mm, giving you more creative space. It has 2 Z-axis metal supporting rod to reduce a lot of sway and make the printing platform more stable during printing.
The Tenlog TL-D5 Dual Filament 3D Printer brings a large building volume 500*mm*500mm*600mm, giving you more creative space. It has 2 Z-axis metal supporting rod to reduce a lot of sway and make the printing platform more stable during printing.
Features
1. Big Building Volume
Dual Filament 3D Printer with building volume 500*mm*500mm*600mm, with 2 Z-axis metal support rods, it overcomes the Z-axis sway, provides a good printing platform stability, and is more precise for printing objects.
2. Dual Material Printing
3. Duplication Mode Printing
4. Mirror Mode Printing
5. Independent 350W power supply for hot bed separately, the maximum temperature of the hot bed can reach 70℃
6. All our IDEX 3D Printers have newest function, power loss recovery, filament runout detection, print from any height.
Specifications
|
Model |
TL-D5 |
|
Additive Manufacturing Accuracy |
±0.1mm |
|
Frame Material |
Aluminum Alloy & Sheet Metal |
|
Platform Board |
Aluminum Alloy & Glass |
|
Nozzle Quantity |
2 |
|
Nozzle Diameter |
0.4mm(Support 0.2mm/0.3mm/0.5mm/0.8mm/1.0mm) |
|
Nozzle Temperature |
Max 250 ℃ |
|
Build Volume |
500mm*500mm*600mm |
|
Layer Thickness |
0.1mm-0.4mm |
|
Printer IO |
16G SD card/USB 2.0 |
|
Screen |
480*272 Resolution Full Color Capacitive Touch Screen |
|
Printing Speed |
10-150mm/s, Recommended 30-60mm/s |
|
Heatbed Temperature |
MAX 70℃ |
|
Supported Filaments |
TPU, PVA, PLA, ABS, HIPS, WOOD, PETG, FLEXIBLE |
|
Filaments Diameter |
1.75mm |
|
Language |
English, Language custom accepted |
|
Support Files |
G-code, STL, jpg, etc. |
|
XY-Axis Positioning Accuracy |
0.011mm |
|
Z-Axis Positioning Accuracy |
0.0025mm |
|
Input Power |
100V-240V@50/60Hz |
|
Output Power |
24V, Max 15A |
|
File Preparation Software |
Cura, Repetier-Host |
|
Operative Systems |
XP, WIN7/8/10, Linux |
|
Voltage Range |
110-120V / 6.8A, 200 - 240V / 3.4A, 50 / 60Hz |
| Machine Size | 90cm*95cm*104cm(W*D*H) |
|
Machine Weight |
28Kg |
| Shipping Box Size |
86cm*90cm*27cm |
|
Volumetric(Dimensional) Weight |
45Kg |
Photo of TL-D5 IDEX 3D Printer
Our Services
Provide a 1-Year Warranty with shipping charges only!
Free shipping for quality problems within 1 year!
Technical support for life!
|
TL-D5 Packing List |
||
|
No. |
Part Name |
Quantity |
|
1 |
Printer host |
1 Set |
|
2 |
H-linkage kit |
1 Set |
|
3 |
Installation & maintenance tool |
2 Boxes |
|
4 |
Nozzle Kits |
2 Sets |
