Our TL-D3 Pro Dual Extruder 3D Printer has Double Nozzles that are independent of each other, allowing it to be printed in Duplication and Mirror mode. You can also choose double different colors or materials to create at the same time. or print soluble support(such as PVA) to precisely implement models that are difficult to lay down. Thanks to the new DMP3d printing system, TL-D3 Pro gives you better creative space and double productivity!
We provide 30 days return and 1 year warranty, here is details
https://www.tenlog3d.com/warranty_d7
Features
1. Dual Material Printing
Temperature, Extruder Speed, Printing Speed, and Infill Density are separately set for each nozzle. Even with different diameter nozzles, the TL-D3 Pro 3D Printer can seamlessly print.
2. Duplication Mode Printing
Double the printing efficiency and save your time, Get the object's twins right away!
3. Mirror Mode Printing
Print two symmetrical models, two nozzles full-time double-drive printing, and immediately get the objects in the mirror.
4. All our IDEX 3D Printers have newest function, power loss recovery, filament runout detection, print from any height.
Specifications
|
Model |
TL-D3 Pro 600W |
|
Additive Manufacturing Accuracy |
±0.1mm |
|
Frame Material |
Aluminum Alloy & Sheet Metal |
|
Platform Board |
Aluminum Alloy & Glass |
|
Nozzle Quantity |
2 |
|
Nozzle Diameter |
0.4mm |
|
Nozzle Temperature |
Max 300℃ when room 20℃ |
| Heatbed Temperature | MAX 110℃ when room 20℃ |
| Working Temperature | 10-50℃ |
|
Build Volume |
300mm*300mm*350mm |
|
Layer Thickness |
0.1mm-0.4mm |
|
Printer IO |
16G SD card/USB 2.0 |
|
Screen |
4.3-inch Resolution Full Color Capacitive Touch Screen |
|
Printing Speed |
10-150mm/s |
|
Supported Filaments |
TPU, PVA, PLA, ABS, HIPS, WOOD, PETG, FLEXIBLE |
|
Filaments Diameter |
1.75mm |
|
Language |
English, French, German, Spanish, Italian, Japanese, Chinese Language custom accepted |
|
Support Files |
G-code, STL, jpg, etc. |
|
XY-Axis Positioning Accuracy |
0.011mm |
|
Z-Axis Positioning Accuracy |
0.0025mm |
|
Input Power |
110V/230V@50/60Hz |
|
Output Power |
24V, Max 25A |
|
File Preparation Software |
Cura, Repetier-Host |
|
Operative Systems |
XP, WIN7/8/10, Linux |
|
Voltage Range |
110-120V, 200 - 240V, 50 / 60Hz |
| Machine Size(W*D*H) | 59cm*52cm*76cm |
|
Machine Weight |
15.6Kg |
|
Shipping Box Size |
66cm*60cm*25cm |
|
Volumetric(Dimensional) Weight |
20.5Kg |
Photo of Double Color 3D Printer
Our Services
Provide a 1-year warranty with shipping charges only!
Free shipping for quality problems within 1 year!
Technical support for life!
Packaging & Shipping
Shipping Box Size: 66cm*60cm*25cm
|
TL-D3 Pro Packing List |
||
|
No. |
Part Name |
Quantity |
|
1 |
Printer Host |
1 Set |
|
2 |
Z/X Gantry Assembly |
1 Set |
|
3 |
Dual Extruder & Nozzle Kits |
1 Set |
|
4 |
Installation & maintenance tool |
2 Boxes |
