GROWATT up-to-date smart grid-tied inverter for single phase residential application, innovative aerial material cover, elegant looking and 45% lighter. The OLED screen and touch button design brings more convenient operation. Leading high efficiency ensures high energy yields of a home system.
Output Type :
SingleCertificate :
ALLSize :
375/350/160mmWarranty :
5years( 10years op)Single Phase to Three Phase Inverter
Growatt Solar Inverter 5kw 6KW 5000TL-X 6000TL-X PV Grid Tie Solar Single Phase On-grid Inverter
Related Parameters :
|
Datasheet |
MIN 5000TL-X |
MIN 6000TL-X
|
|
Input Data
|
||
|
Max. recommended PV power(for module STC)
|
7000W
|
8100W
|
|
Max. DC voltage
|
550V
|
550V
|
|
Start voltage
|
100V
|
100V
|
|
MPP work voltage range/ nominal voltage
|
80V-550V /360V
|
80V-550V /360V
|
|
Max. input current
|
12.5A/12.5A
|
12.5A/12.5A
|
|
Max. short-circuit current
|
16A/16A
|
16A/16A
|
|
Number of independent MPP trackers / strings per MPP tracker
|
2/1
|
2/1
|
|
Output (AC)
|
||
|
Rated AC output power
|
5000W
|
6000W
|
|
Max. AC apparent power
|
5000VA
|
6000VA
|
|
Max. output current
|
22.7A
|
27.2A
|
|
AC nominal voltage
|
230V(160V-300V)
|
230V(160V-300V)
|
|
AC grid frequency
|
50Hz/60Hz,±5Hz
|
50Hz/60Hz,±5Hz
|
|
Adjustable power factor
|
0.8leading...0.8lagging
|
0.8leading...0.8lagging
|
|
THDi
|
<3%
|
<3%
|
|
AC connection
|
Single phase
|
Single phase
|
|
Efficiency
|
|
|
|
Max.efficiency
|
98.40%
|
98.40%
|
|
Euro weighted efficiency
|
97.50%
|
97.50%
|
|
MPPT efficiency
|
99.90%
|
99.90%
|
|
Protection Devices
|
||
|
DC reverse polarity protection
|
yes
|
yes
|
|
DC switch
|
yes
|
yes
|
|
DC surge protection
|
Type II
|
Type II
|
|
Output over current protection
|
yes
|
yes
|
|
Output over voltage protection-varistor
|
yes
|
yes
|
|
Ground fault monitoring
|
yes
|
yes
|
|
Grid monitoring
|
yes
|
yes
|
|
Integrated all - pole sensitive leakage current monitoring unit
|
yes
|
yes
|
|
General Data
|
||
|
Dimensions (W / H / D) in mm
|
375/350/160
|
375/350/160
|
|
Weight
|
10.8KG
|
10.8KG
|
|
Operating temperature range
|
–2 5 ° C . . . + 6 0 ° C
|
–2 5 ° C . . . + 6 0 ° C
|
|
Noise emission (typical)
|
≤25 dB(A)
|
≤25 dB(A)
|
|
Altitude
|
4000m
|
4000m
|
|
Self-Consumption night
|
< 0.5W
|
< 0.5W
|
|
Topology
|
Transformerless
|
Transformerless
|
|
Cooling concept
|
Natural
|
Natural
|
|
Environmental Protection Rating
|
IP65
|
IP65
|
|
Relative humidity
|
100%
|
100%
|
|
Features
|
||
|
DC connection
|
H4/MC4(opt)
|
H4/MC4(opt)
|
|
AC connection
|
Connector
|
Connector
|
|
Display
|
OLED+LED
|
OLED+LED
|
|
Interfaces: RS485 / USB /Wi-Fi/ 4G / RF
|
yes / yes /opt / opt / opt
|
yes / yes /opt / opt / opt
|
|
Warranty: 5 years / 10 years
|
yes / opt
|
yes / opt
|
