Senhaix 8800 Dual Band Radio Red

UHF VHF Dual Band Handheld Radio Ham Radio
Product Details

Basic Features

Dual band

Dual Watch

Dual Standby

Scan Function

Channel Storage

Flashlight & SOS Strobe

Channel Mode & Frequency Mode

IP56 Rainproof

2 Charging Method

FM Radio

DTMF Function

211 CTCSS and 51 DCS Tones

1750Hz Tone Encryption

VOX Delay

VOX For Hand-free Operation


Technical Specifications


General
Frequency Range UHF & VHF
Channel Capacity 128 Channels
Channel Step 25KHz(Wide Band), 12.5KHz(Narrow Band)
Frequency Stability ±2.5ppm
Operating Voltage 7.4V DC  ± 20%
Operating Temperature -20 ~ +60
Antenna Impedance 50Ω
Dimension 134*60*38mm(with battery pack)
Weight 270g(with battery pack, antenna)
Transmitter

Wide Band Narrow Band
Output Power 5W 5W
Modulation Mode 16KφF3E 8KφF3E
Adjacent Channel Power ≥65dB ≥60dB
Singal Noise Ratio ≤-40dB ≤-40dB
Parasitic Harmonic ≤65dB ≥60dB
Spurious Emission ≤-36dBm ≤-36dBm
Audio Response 300Hz-3KHz 300Hz-3KHz
Audio Distortion ≤5% ≤5%
Receiver

Wide Band Narrow Band
Sensitivity -120dBm (20db SINAD) -120dBm (20db SINAD)
Intermodulation ≥60dB ≥55dB
Adjacent Channel Selectivity ≥60dB ≥55dB
Spurious Rejection ≥60dB ≥55dB
Audio Response 300Hz-3KHz 300Hz-3KHz
Signal to Noise Ratio ≥45dB ≥40dB
Audio Distortion ≤5% ≤5%
Audio Output Power 1W 1W
