RS232 4 Inch 1D/2D Embedded Thermal Label Kiosk Printer HCC-EU1121

HCC-EU1121 has different paper width optional and it's compatible with CPCL command.


Product Details

110mm Auto Cutter Kiosk Thermal Label Printer Modules HCC-EU1121

HCC-EU1121 support RS-232/USB interface and 4 inch label paper. Besides, it can also take many forms but they all have one thing in common; being are hidden away inside a machine. One reason there are so many different kiosk printers on the market is that the applications for them are so diverse. Their purpose can be anything from a fuel pump issuing a receipt, a ticket machine on a railway platform, or a check-in booth in a hospital waiting room.


Feature

  • Thermal printer mechanism
  • Easy paper loading
  • Support USB + serial communication
  • Automatic paper feeding
  • Auto-cutter with long lifespan
  • Easy to integrate into kiosk designs


Specification

Printing Method

Thermal Line

Printing Speed

150mm/s(25% Print Density)

Resolution

8 dots/mm, 800 dots/line

Effective Printing Width

100mm

PaperRollDiameter

180MM

Character Set

ASCII, GB18030(Chinese), BIG5 (24*24)

Print Font

Code page, ASCII 9×24, 12×24

Paper Type

Label paper

Paper Thickness

0.06~0.15mm

Paper Width

103± 0.25mm

TPH

50km

Barcode

1D:UPC-A,UPC-E,EAN-13,EAN-8,CODE39,ITF25,CODEBAR,CODE93,CODE128
2D:QRCODE, PDF417, DATAMATRIX

Emulation

CPCL

Interface

RS-232/USB

Paper Supply Method

Manual loading

Power Supply

DC24V±10%, 2A

Auto cutter Type

Guillotine

Auto cutter Life

1,000,000 cuts

Cutting Method

Full / Partial cut

Dimension(LXWXH)

398mmX184mmX179mm
