Functions
1. VOX
2. Scan
3. Scrambler
4. Busy Channel Lockout
5. SOS
6. Battery Voltage Indicator
7. TOT
8. Wide/Narrow Band
9. High/Low Power
10. Waterproof
11. Dustproof
12. Noise Cancellation
General
Frequency Range
UHF
Channel Capacity
16 Channels
Channel Step
25KHz(Wide Band), 12.5KHz(Narrow Band)
Frequency Stability
±2.5ppm
Operating Voltage
7.4V DC ± 20%
Operating Temperature
-20℃ ~ +60 ℃
Antenna Impedance
50Ω
Dimension
136*60*36mm
Weight
260g
Transmitter
Output Power
5W
Modulation Mode
16K0F3E
Adjacent Channel Power
≥65dB
Singal Noise Ratio
≤-40dB
Parasitic Harmonic
≤65dB
Spurious Emission
≤-36dBm
Audio Response
300Hz-3KHz
Audio Distortion
≤5%
Receiver
Sensitivity
-120dBm (20db SINAD)
Intermodulation
≥60dB
Adjacent Channel Selectivity
≥60dB
Spurious Rejection
≥60dB
Audio Response
300Hz-3KHz
Signal to Noise Ratio
≥45dB
Audio Distortion
≤5%
Audio Output Power
1W
