Quickly identify the screen 1D/2D code
Very large reading window
No plugins, lightning billing
Body and data line integration design
Non-slip drop design
Compatible with a variety of systems
Quickly identify the screen 1D/2D code
Very large reading window
No plugins, lightning billing
Body and data line integration design
Non-slip drop design
Compatible with a variety of systems
Mobile Payment Box
HS-2001B is an image platform launched by HCCTG and it is especially designed for mobile payment.It adopts the world's leading image photographing optical technology.With the eternal superior bar scanning and digital image capturing function, it can easily and quickly identify universal one-dimensional barcodes and two-dimensional codes(QR codes).
1. Stylish, compact and space saving.
2. Quickly read paper 1D / 2D barcodes, barcodes on electronic screens, scan once it is plugged.
3. With image-sensing and automatic wake-up function, it can effectively reduce power consumption and wear and tear of core components.
4. Solid-state hardware design ensures higher stability and reliability.
Specification
|
Performance |
|
|
Image Sensor |
640×480 CMOS |
|
Ambient light intensity |
0~100000Lux |
|
Symbolize |
1D: Code 128,UCC/EAN-128,AIM 128,EAN-8,EAN-13, ISSN, ISBN,UPC-E,UPC-A,Interleaved 2 of 5,ITF-6,ITF-14,Matrix 2 of 5(European Matrix 2 of 5),Industrial 25,Standard 25,Code 39,Codabar,Code 93,Code 11,Plessey,MSI-Plessey,RSS-14,RSS- Limited,RSS-Expand 2D:PDF417,Data Matrix,QR,Micro QR |
|
Resolution |
≥5mil |
|
Typical Depth of Field |
QR CODE( 30MIL) 0-15CM CODE 128 (10MIL) 0-12CM |
|
Scan Angle |
|
|
Pitch |
±60°@ 0°Roll and 0° Skew |
|
Roll |
360°@ 0°Pitch and 0° Skew |
|
Skew |
±55°@ 0°Roll and 0° Pitch |
|
Symbol Contrast |
≥30% |
|
Interface |
RS-232, USB |
|
Physical |
|
|
Dimensions |
102*82*73 mm(L*W*H) |
|
Weight |
USB:228g RS232:261g |
|
Notification |
Beep,LED indicator |
|
Current |
|
|
Maximum |
<200mA |
|
Operating |
150mA±15mA |
|
Standby |
80mA±2mA |
|
Environmental |
|
|
Operating Temperature |
-20℃~50℃ |
|
Storage Temperature |
-40℃~70℃ |
|
Humidity |
5%~95%(non-condensing) |
