High Voltage Lithium Battery 192V 256V 360V 512V 50Ah Deep Cycle Lithium ion LiFePO4 Battery Storage System
10 years warranty, more than 20 years lifetime
UL CE MSDS certificates
High Voltage Lithium Battery 192V 256V 360V 512V 50Ah Deep Cycle Lithium ion LiFePO4 Battery Storage System
10 years warranty, more than 20 years lifetime
UL CE MSDS certificates
Warranty :
12 yearsPayment :
T/T,Credit Card, Paypal, Western UnionCertification :
CE, UN38.3, ULMaterial :
3.2v 50ah battery cellCycle Life :
More than 6000timesMaintenance Type :
Free MaintenanceAmpere :
100ah, 200ah, 300ah,,,etcVoltage :
96V 192V 240V 360V 384VSealed Type :
Sealed
Specifications
| MODEL | 5.12KWH | 7.68KWH | 10.24KWH | 12.8KWH | 15.36KWH | 17.92KWH | 20.48KWH | 23.04KWH | 25.6KWH | ||
| Battery Module |
(2.56kWh, 51.2V, 34kg，600/355/145) |
||||||||||
| Number of Modules | 2PCS | 3PCS | 4PCS | 5PCS |
6PCS |
7PCS | 8PCS | 9PCS | 10PCS | ||
| Nominal Voltage | 102.4V | 153.6V | 204.8V | 256V | 307.2V | 358.4V | 409.6V | 460.8V | 512V | ||
| Operation Voltage Range(V) | 94.4~113.6 | 141.0~170.4 | 188.8~227.2 | 236~284 | 283.2~340.8 | 330.4~397.6 | 377.6~454.4 | 424.8~511.2 | 472~568 | ||
| Weight(KGS) | 83 | 117 | 151 | 185 | 219 | 253 | 287 | 321 | 355 | ||
| Battery Type | Lithium iron phosphate(LFP) |
|
|
|
|
|
|
|
|
||
| Standard Charge/Discharge Current | 25A@0.5C |
|
|
|
|
|
|
|
|
||
| Max Charge/Discharge Current | 50A@1C |
|
|
|
|
|
|
|
|
||
| IP Protection | IP65 |
|
|
|
|
|
|
|
|
||
| Installation | Wall Mounted or Floor Mounted |
|
|
|
|
|
|
|
|
||
| Operation Temperature | 0℃~45℃ |
|
|
|
|
|
|
|
|
||
| Features |
|
|
|
|
|
|
|
|
|
||
| DOD | 80%（can be 100%) |
|
|
|
|
|
|
|
|
||
| Cycle Life | 6000Cycles |
|
|
|
|
|
|
|
|
||
| Warranty | 10Years |
|
|
|
|
|
|
|
|
||
| Communication | CAN/RS485 |
|
|
|
|
|
|
|
|
||
| Certification | CE IEC UL CEC UN38.3 |
|
|
|
|
|
|
|
|
||
Details of Lithium Battery
Projects of Lithium Battery
All lithium batteries have BMS inside.
Our Lithium Battery Modular can connect in parallel to reach 48v 20kwh, 50kwh, 100kwh,,etc.
Also offer high voltage lithium battery cabinet, such as 96v, 120v, 144v, 192v, 240v, 360v,,,etc.
We offer one stop solution with solar panel, storage inverter,lithium battery and battery cabinet.
Fast delivery, free design, 100% new battery cells.
Accept OEM and ODM service.
Pls contact us without hesitate if you are intersted in.
