Handheld UHF VHF 5W Professional FM Transceiver 2 Way Radio

Handheld FM Transceiver 1600mAh communication working 2 way radio
Product Details

Handheld UHF Professional FM Transceiver 2 Way Radio


Product Description:

·We call HYDX-A6 a business little expert, with a display and rich functions. By side key editing, we can quickly open the custom function, support listening to FM broadcast, and can be applied to various life office scenes.

·Professional two way radio with 199 capacity channels; FM radio,fun to listen and always with great signal to enrich your daily life when you have nothing to do

·Long range with perfect size make them easy to hold; super compact for long life using; gets long range with the included antenna and exceptional ·1600 mAh rechargeable Li-ion battery; each radio includes its accessory

VOX Mode for hands-free provides great reception and transmit clarity to keep on communicate with fellow co-worker; awesome for business like security team;construction; fire departments

·Easy to set keyboard with your desired;If you need,you can also lock the keypad to prevent channel change caused by accidental touch.

·1600mAh Li-ion battery provides 8-12 hours continuous use for your outside activity.



Main Functions

1.VFR/MR/CH Working Modes

2.Side Key Programming

3.Password Setting

4.Tail Elimination

5.DTMF Decode/Encode

6.PTT ID/ANI

7.FM Radio

8.Key Lockout

9.BCLO

10.Scan/Priority Scan

11.High/Low Power

12.Wide/Narrow Bandwidth

13.VOX/IVOX

14.TOT

15.CTCSS 50/DCS 105


Technical Specification

GENERAL
    Frequency Range

    UHF:400-470MHz

    VHF:136-174MHz

    RF Output Power     H:≤5W   L:≤2W
    Channels     199
    Channel Spacing     Wide:25KHz   Narrow:12.5KHz
    CTCSS/DCS     50 CTCSS / 105 DCS
    Antenna Impedence     50Ω
    Operating Temperature     -20℃+50℃
    Operating Voltage     DC 7.4V
    Battery Type     1600mAh
    Dimension(Excluding antenna)     112.5(H)×57.5(W)×36.5(D)mm
    Weight(Battery,Antenna Including)     About 230g
TRANSMITTER
    Output Power

    H:≤5W

    L:≤2W

    Modulation Mode     F3E
    FM Noise

    ≤ -45 dB

    Modulation Distortion     ≤ 5%
    Spurious and Harmonics     -65 dB
RECEIVER
    Reference Sensitivity     ≤ -123 dBm
    Adjacent Channel Selectivity     ≤ -65 dB
    Inter-modulation response immunity     ≤ -55 dB
    S/N

    ≥ 45 dB

    Rated Output Power     ≤750mW
    Rated Audio Distortion     ≤5%
Packing&Delivery


Two-way Radio Walkie Talkie Gift Box, 10 pcs / carton.


*  1 x HYDX A6


*  1 x Antenna


*  1 x Battery


*  1 x Charger


*  1 x Belt Clip


*  1 x Hand Strap


*  1 x User Manual


*  1 x Adapter
