Handheld Bluetooth Barcode Scanner

iDPRT bluetooth handheld scanner,HS-M300 /HS-M300C Barcode Scanner,Intelligent Automatic scanning with manual control movable scanning

Product Details

Product Information:

Model: HS-M300 /HS-M300C, handheld Bluetooth Barcode Scanner

Product Features：

Scanning speed peak up to 500 times/sec;
Configure filters for stronger anti-jamming;
Fast charging, long standby;
Bluetooth connection, convenient and quick;
Support for SPP protocol (Only suitable for HS-M300S) Support for HID,GATT protocol;
Equipped with Andriod, iOS SDK for more convenient application development;
Configure dual LED, vibrating motor, buzzer

Product Advantages：

Compact and easy to carry

Simple appearance,light luxury texture to enhance your tasts

Long standby time which charge for 3 hours,continous scanning,standby for one month

Multi-scenario application

Product Specification：

Model		HS-M300	HS-M300C
Real-time data upload function		Support
Maximum data staging storage		256
Bluetooth Chip	Model	TLSR826X
	Protocol version number	4.2 BLE
	Configuration protocol	HID, GATT
Scanning module	Illuminant	White LED
	Aiming	Red LED
	Sensor	Linear, CCD sensor	640*480,CMOS
	Data reading distance	PCS 90%: 50cm（barcode density	20~310mm
		20miles/0.5mm,PCS 90%
	Contrast ratio	PCS 45%（barcode density 4 miles/0.1mm）	≥ 25%
	Resolution ratio	PCS 90%（barcode density 4 miles/0.1mm）	PCS 90%, CODE 39: ≥ 4mil/0.1mm
	Scanning angle	5° ~60°	Roll 0-360° ; Pitch ±60° ; Skew ±60°
	Ambient light	5° ~60°	0~10000 Lux
Support for barcode type	1D	UPC/EAN/JAN, EAN128, Code39, Code32, Code128, CODABAR/NW7, Interleave 25, Industrial 25,
		Matrix25, MSI/PLESSEY, Telepen, Code93, Code11, China Postage, Code26, LCD25, GS1 DataBar
		Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded
	2D	-	QR Code, DataMatrix, PDF417, etc.
Firmware upgrade mode		OTA
Filter		Allocate
Software development kit		Android, iOS
Battery performance	Charging time	75min
	Scanning times	20,000 times
	Standby time	30 days
Environmental parameter	Operation	0℃ ~ 50 ℃ (32 ℉ ~ 122 ℉ )，Relative humidity
	Storage	-20℃ ~ 70 ℃ (-4 ℉ ~ 158 ℉ )，Relative humidity
Physical parameter	Size	80×30×20mm
