HCC-T80S has 4.5-inch HD screen, 4G full Netcom and with android 8.1 system.
HCC-T80S has 4.5-inch HD screen, 4G full Netcom and with android 8.1 system.
Ruggged Android 9.0 Handheld Wireless PDA Terminal Data Collector Perfect For Warehouse
HCC-T80S has features of durable construction and sealing deliver reliable operation and maximize worker uptime, delivers full wireless coverage for applications inside and outside of the four walls, allowing real-time access to critical data and more.
Specifications
|
Performance |
|
|
CPU |
Cortex-A53Quad-core 64-bit 2.0GHz high-performance processor |
|
RAM+ROM |
2GB+16GB |
|
Expand memory |
Micro SD(TF) Supports up to 128GB |
|
System |
Android 9.0 |
|
Data communication |
|
|
WLAN |
Dual-band 2.4GHz/ 5GHz, SupportingIEEE 802 a/b/g/n/ac protocol |
|
WWAN |
2G:GSM (850/900/1800/1900MHz) |
|
3G:WCDMA (850/900/1900/2100MHz) |
|
|
4G:FDD:B1/B3/B4/B7/B8/B12/B20 |
|
|
TDD:B38/B39/B40/B41 |
|
|
Bluetooth |
Support Bluetooth 2.1+EDR/3.0+HS/4.1+HS Transmission distance 5-10 meters |
|
GPS |
SupportGPS,Galileo,Glonass,Beidou |
|
Data collection |
|
|
Barcodescanning(Optional) |
|
|
1D Linear scanner |
Mindeo SE966 Honeywell N4313 |
|
1D Symbologies |
Code128,EAN-13,EAN-8,Code39,UPC-A,UPC-E,Codaber,Interleaved 2 of 5,China post 25,ISBN/ISSN,Code93,UCC/EAN-128, GS1 Databar, HIBC, etc. |
|
2D Imagerscanner |
Newland EM3090 Honeywell N3603 Honeywell N6603 |
|
2D Symbologies |
PDF417,Micro PDF417,GS1 Composite,Aztec Code,Data Matrix,QR Code,Micro QR Code,MaxiCode,Hanxin Code, etc. |
|
Camera |
|
|
Rear camera |
8MP HD camera,Support auto focus, Flash,Anti-shake,Macro shooting |
|
NFC (Optional) |
|
|
Frequency |
13.56MHz |
|
Protocol |
Support ISO14443A/B, 15693 agreement |
|
Distance |
2cm-5cm |
|
Physical parameter |
|
|
Dimensions |
166mm×77.5mm×22mm |
|
Weight |
＜500g |
|
Display |
4.5 inch IPS color display with resolution 480*854 |
|
TP |
CorningGorilla glass, supports multi-touch Supported gloves and we thands |
|
Battery capacity |
Rechargeable polymer battery (3.8V 4200mah) removable |
|
Standby time >350 hours |
|
|
Working time > 12 hours |
|
|
Charging time＜4H, using standard power adapter and data cable |
|
|
Expansion Card slot |
PSAM x 2, Micro SIM card x 1 , TF card × 1 |
|
Communication interface |
Type-C USB x 1, OTG,POGO Pin x 1 |
|
Audio |
Speaker (mono),Microphone,Earpiece |
|
Keypad |
Support touch screen soft keypad and physical keypad |
|
Sensor |
GravitySensor,Vibration motor |
|
Language/input method |
|
|
Input |
English,Pinyin,Five strokes,Handwriting input,Support soft keypad |
|
Language |
Language packs in Simplified Chinese, Traditional Chinese, English, Korean, Japanese, Malaysian, etc. |
|
User environment |
|
|
Operating temperature |
-20℃ - 55℃ |
|
Storage temperature |
-40℃ - 70℃ |
|
Environment humidity |
5%RH--95%RH(no condensation) |
|
Drop specification |
6 sides Supports 1.5 meters drops and 30 times to the concrete within the operating temperature |
|
Rolling test |
500×0.5m rolling for 6 sides |
|
Protection level |
IP66 |
|
Accessories |
|
|
Standard |
Adapter,Data cable,Protective film, Instruction manual |
