Datasheet
|
SPF 3000TL LVM-24P
|
SPF 3000TL LVM-48P
|
|
Battery voltage
|
24VDC
|
48VDC
|
|
INVERTER OUTPUT
|
|
RATED POWER
|
3000VA/ 3000W
|
3000VA/ 3000W
|
|
Parallel Capability
|
Yes
|
Yes
|
|
AC Voltage Regulation
(Battery Mode)
|
120VAC ± 5%
@ 50/60Hz
|
120VAC ± 5%
@ 50/60Hz
|
|
Surge Power
|
6000VA
|
6000VA
|
|
Efficiency (Peak)
|
93%
|
93%
|
|
Waveform
|
Pure sine wave
|
Pure sine wave
|
|
Transfer Time
|
10 ms (For Personal Computers); 20 ms (For Home Appliances)
|
10 ms (For Personal Computers); 20 ms (For Home Appliances)
|
|
SOLAR CHARGER
|
|
Maximum PV Array Power
|
2000W
|
4500W
|
|
MPPT Range @ Operating Voltage
|
30VDC ~ 115VDC
|
30VDC ~ 115VDC
|
|
Maximum PV Array Open Circuit Voltage
|
145VDC
|
145VDC
|
|
Maximum Solar Charge Current
|
80A
|
80A
|
|
Maximum Efficiency
|
98%
|
98%
|
|
Standby Power Consumption
|
2 W
|
2 W
|
|
AC CHARGER
|
|
Charge Current
|
60A
|
40A
|
|
AC Input Voltage
|
120 VAC
|
120 VAC
|
|
Selectable Voltage Range
|
95-140 VAC (For Personal Computers) ;
65-140 VAC (For Home Appliances)
|
95-140 VAC (For Personal Computers) ;
65-140 VAC (For Home Appliances)
|
|
Frequency Range
|
50Hz/60Hz (Auto sensing)
|
50Hz/60Hz (Auto sensing)
|
|
PHYSICAL
|
|
Dimension (D/W/H) in mm
|
130/350/455
|
130/350/455
|
|
Net Weight (kgs)
|
11.5
|
11.5
|
|
OPERATING ENVIRONMENT
|
|
Humidity
|
5% to 95% Relative
Humidity(Non-condensing)
|
5% to 95% Relative
Humidity(Non-condensing)
|
|
Operating Temperature
|
0°C - 55°C
|
0°C - 55°C
|
|
Storage Temperature
|
-15°C - 60°C
|
-15°C - 60°C
|
