SMD wire connector which can replace 2060 series, it's easy to setup. There are 1 pin, 2 pin and 3 pin. It can be equipped with a jumper to combine two connectors.
SMD wire connector which can replace 2060 series, it's easy to setup. There are 1 pin, 2 pin and 3 pin. It can be equipped with a jumper to combine two connectors.
Electronic lighting smd single wire connector for led
Features of Smd wire connector
Specifications of Single wire conenctor
| Product Name: |
smd wire connectors |
Application: |
Junction box/electric power |
| Wiring method: |
Insert |
Wire range: | 24 - 18 AWG |
| Strip length: |
6-7 mm/0.24 - 0.28 in |
Cross section: |
0.2 - 0.75 mm2 |
| Voltage(max.): |
600V |
Rated Current: |
9A |
| Insulation material: | PA66, UL94-V0 | Contact plating: |
Tin-plated |
Real object and size of Smd wire connector
Packaging and application of SMT terminals
SMT terminals Use strip packaging to facilitate automated production,
The product uses reflow soldering and is applied to PCB boards such as hard light strips, hard light bars, hard light panels, etc.
SMT terminals optional accessories:
When two B07 SMD terminal blocks are needed for connection, the B07J jumper can be selected, which has the same number of 1P, 2P and 3P pins as the B07 terminal block.
