Automatic Four-column Melamine Tableware Making Machine

  • Automatic high efficiency and stable production
  • Melamine related machines and moulds since 2002


Features and benefits
  • Support Service :

    Life-time Service
  • Trainning Service :

    Yes
  • Machine Weight :

    8600KG
  • Machine Dimension :

    2.3*1.78*2.9 M
Product Details

Classification of hydraulic press machine

  • The structural classification of hydraulic presses can be divided into single-arm hydraulic presses, gantry hydraulic presses, and four-column hydraulic presses.
  • The control form classification can be divided into manual, automatic, semi-automatic, etc.
  • The movement form is divided into downward pressure type and upper top type.
  • Shunhao melamine tableware hydraulic press machine is a four-column automatic press type tableware making machine.


300T Double color Melamine Moulding Machine


Technical Parameters

No.

Content

DTM 300

1

Main Cylinder Nominal Pressure

300Tons

3

Maximum Working Pressure

210kg/cm2

4

Main Cylinder Piston Diameter

Ø450mm

5

Main Cylinder Working Stroke

550mm

6

Adjustable Table Distance

500~850mm

7

Heating Plate Size

720*720/780*720mm

8

Working Layers

1 layer

9

Heating Plate Material

45#

10

Tension Column (Heat Treatment Grinding)

Ø120*2400mm

11

Oil Hydraulic Pump

21Mpa

12

Motor Specifications

15HP

13

Heating Sheet Total Power

27.45KW

14

Machine Total Power

38.45KW

15

Machine Size(length * width * height)

2.3*1.78*2.9 M

16

Machine Weight

8600KGS

PS: Specifications subject to change without notice


2 color melamine molding machine


FAQ

Q: How can I get the machine I want?

A: We will give professional advice according to the needs of customers' products, customers need to inform all the required details. We will provide the best solution.

Q: Is there a machine installation service?

A: 1. Shunhao Machine will arrange professional engineers to install the machine for free in your factory (you just need to pay for round-trip airfare, hotel)

2. Arrange professional staff to train machine operation methods and emergency treatment methods for free

3. Provide overseas after-sales service, online video guidance and answer

Q: What's the delivery time for machine?

A: 20-50 days after receiving the deposit, depending on the machine order quantity and machine model.

Q: What is the package for melamine ware compression machine?

A: The weight of the SHUNHAO brand machinery is the standard weight, it is recommended to transport the whole cabinet (FCL=FULL CONTAINER LOAD), film packaging, use wood to fix the four corners of the base to prevent movement; then thicken the wire The zipper is fixed in the container, so that the machine will not move or shake during transportation, ensuring that the machine is perfectly transported to your factory.

Q: What should I do if the machine can't run normally?

A: The melamine tableware molding machine from Shunhao has strict quality control and quality inspection, saving customers time and money. If the machine fails to work, our engineers will provide  online service to provide a quick solution by directly communicating using video & pictures.

melamine ware making machine manufacturers
