22kW RS485 3 phase solar pump inverter with mppt and vfd

INTRODUCTION

Solar pumping inverter obtains DC electric energy from the photovoltaic cell and converts it into electric energy

to drive the water pump. According to the intensity of sunlight, the inverter adopts MPPT algorithm to adjust the

output frequency and make maximum use of solar energy.
SWP series solar pumping inverter is a flexible, easy-to-use and economical solar pumping inverter launched by

Days energy according to the differentiated needs of customers. It aims to provide customers with economic and

comprehensive economic benefit solutions.


Product Details

System application:

Solar Pump Solution is mainly used in the fields of daily life water, agricultural and forestry irrigation, desert management, livestock water, village and town water supply.



MAIN FEATURES

1. Max.power point tracking technology is adopted, and the efficiency > 99%.
2. It can drive three-phase AC pump.
3. Fully automatic operation control, soft start and soft stop, unattended.
4. Perfect system protection mechanism, overvoltage, undervoltage, overcurrent, short circuit, lack of phase, pump drying and other protection functions.
5. Flow and energy display, RS485 function.
6. DC and AC input power supply.



MAIN FUNCTION

1.Flow and energy display
2.MPPT and CVT
3.Auto sleep and wake up run
4.Low frequency stop protection
5.Water level detect and alarm function
6.Minimum power input and maximum current protection
7.Driving for AM

8.Dry run protection

Production parameter

Item \Model
SWP4KH-V1
SWP5K5H-V1
SWP7K5H-V1
SWP11KH-V1
SWP15KH-V1
SWP18K5H-V1
SWP22KH-V1
SWP30KH-V1
SWP37KH-V1
PV Input









Max. input DC voltage
800V
800V
800V
800V
800V
800V
800V
800V
800V
Recommended MPPT Voltage
485~750Vdc
485~750Vdc
485~750Vdc
485~750Vdc
485~750Vdc
485~750Vdc
485~750Vdc
485~750Vdc
485~750Vdc
Max. MPPT Effiffifficiency
99%
99%
99%
99%
99%
99%
99%
99%
99%
Number of String
1 1 1 1 1 1 1 1 1
A.C. Input









Voltage
330~460Vac(3PH) When PV and power grid are required to be mixed, accessory products need to be added
330~460Vac(3PH) When PV and power grid are required to be mixed, accessory products need to be added
330~460Vac(3PH) When PV and power grid are required to be mixed, accessory products need to be added
330~460Vac(3PH) When PV and power grid are required to be mixed, accessory products need to be added
330~460Vac(3PH) When PV and power grid are required to be mixed, accessory products need to be added
330~460Vac(3PH) When PV and power grid are required to be mixed, accessory products need to be added
330~460Vac(3PH) When PV and power grid are required to be mixed, accessory products need to be added
330~460Vac(3PH) When PV and power grid are required to be mixed, accessory products need to be added
330~460Vac(3PH) When PV and power grid are required to be mixed, accessory products need to be added
Frequency
50Hz/60Hz(±3%)
50Hz/60Hz(±3%)
50Hz/60Hz(±3%)
50Hz/60Hz(±3%)
50Hz/60Hz(±3%)
50Hz/60Hz(±3%)
50Hz/60Hz(±3%)
50Hz/60Hz(±3%)
50Hz/60Hz(±3%)
A.C. Output









Max. applicable motor output power
4kW
5.5kW
7.5kW
11kW
15kW
18.5kW
22kW
30kW
37kW
Rated Output Voltage
380-460Vac 3-phase
380-460Vac 3-phase
380-460Vac 3-phase
380-460Vac 3-phase
380-460Vac 3-phase
380-460Vac 3-phase
380-460Vac 3-phase
380-460Vac 3-phase
380-460Vac 3-phase
Output Frequency Range
0~50/60Hz
0~50/60Hz
0~50/60Hz
0~50/60Hz
0~50/60Hz
0~50/60Hz
0~50/60Hz
0~50/60Hz
0~50/60Hz
Rated output current
10A
13A
18A
21A
29A
36A
42A
57A
71A
Mechanical data









Dimensions(W/H/D)(mm)
252/195/230
340/273/288
340/273/288
340/273/288
540/310/295
540/310/295
540/310/295
594/334/301
594/334/301
Weight
3.2kg
4.9kg
4.9kg
5.2kg
9kg
9kg
9kg
16kg
16kg
System









Protection Level
IP20
IP20
IP20
IP20
IP20
IP20
IP20
IP20
IP20
Operating Temperature
-25℃ to +50℃,above 50℃ need derate operating
-25℃ to +50℃,above 50℃ need derate operating
-25℃ to +50℃,above 50℃ need derate operating
-25℃ to +50℃,above 50℃ need derate operating
-25℃ to +50℃,above 50℃ need derate operating
-25℃ to +50℃,above 50℃ need derate operating
-25℃ to +50℃,above 50℃ need derate operating
-25℃ to +50℃,above 50℃ need derate operating
-25℃ to +50℃,above 50℃ need derate operating
Cooling Way
Force cooling
Force cooling
Force cooling
Force cooling
Force cooling
Force cooling
Force cooling
Force cooling
Force cooling
Display
LED
LED
LED
LED
LED
LED
LED
LED
LED
Communication interface
RS485
RS485
RS485
RS485
RS485
RS485
RS485
RS485
RS485
Altitude
1000m; above 1000m need derate operating
1000m; above 1000m need derate operating
1000m; above 1000m need derate operating
1000m; above 1000m need derate operating
1000m; above 1000m need derate operating
1000m; above 1000m need derate operating
1000m; above 1000m need derate operating
1000m; above 1000m need derate operating
1000m; above 1000m need derate operating
Noise Emission
<65dB
<65dB
<65dB
<65dB
<65dB
<65dB
<65dB
<65dB
<65dB
Compliance
EN 50178; IEC/EN 62109-1; IEC 61800
EN 50178; IEC/EN 62109-1; IEC 61800
EN 50178; IEC/EN 62109-1; IEC 61800
EN 50178; IEC/EN 62109-1; IEC 61800
EN 50178; IEC/EN 62109-1; IEC 61800
EN 50178; IEC/EN 62109-1; IEC 61800
EN 50178; IEC/EN 62109-1; IEC 61800
EN 50178; IEC/EN 62109-1; IEC 61800
EN 50178; IEC/EN 62109-1; IEC 61800
Dimension(W/H/D)
265/330/150(mm)
265/330/150(mm)
265/330/150(mm)
265/330/150(mm)
265/330/150(mm)
265/330/150(mm)
265/330/150(mm)
265/330/150(mm)
265/330/150(mm)
