Technical Features
![](/storage/uploads/images/202205/12/fabb9642a33fc6df77ef7fb604be6195.jpg)
|
![](/storage/uploads/images/202205/12/4320ab3328926e4498f6807516b0b12e.jpg)
|
![](/storage/uploads/images/202205/12/0c83c6174181939d2f856e3b101e2025.jpg)
|
High
power density
|
Modular
design with transformer
|
High
efficiency
|
20 KVA power module in 2U height, saving great amount of space, easy for capacity expansion.200kVA with footprints of about 0.5m2, saving valuable data center space
|
Up to 20 power modules in parallel online hot-swappable N+X redundancy. Up to 60KVA with built-in isolation transformer , meeting different requirement for customer
|
Green and energy saving due to smart sleeping mode: Up to 99% system efficiency, input PF>0.99 while THDi <3%
|
![](/storage/uploads/images/202205/12/98455dd4b0040c7ed3ed03233fedcb38.jpg)
|
![](/storage/uploads/images/202205/12/db5066cb9ca34cb131d55a33062315b1.jpg)
|
![](/storage/uploads/images/202205/12/2664e8d6acc3bacf703da8e482ee204c.jpg)
|
Intelligent
charging management
|
Independent
air channel
|
High
reliability
|
The intelligent charger for each module can intelligently control the whole process of charging & discharging, effectively improve the life time of the battery
|
Cooling air runs in isolated channel ,keeping PCB free of dust
|
Integrated IGBT in one module, less failure points with higher performance and reliability
|
![](/storage/uploads/images/202205/12/ea9ad4f37732b0ef9a8f71baa3265a8c.jpg)
|
![](/storage/uploads/images/202205/12/89b0dc963db43dfa9db284b8bc0dd265.jpg)
|
![](/storage/uploads/images/202205/12/6683220b499f9f43268563f13b41997f.jpg)
|
Battery
cold start
|
Easy
connection access
|
Multi
communication interface
|
UPS can be powered on from the battery without utility. It will add great value to your workflow by providing on-demand power.
|
Top and bottom cable entry connection are supported, more convenient for site installation
|
Provide RS232, RS485, USB, SNMP & programmable dry contacts.7" touch color LCD with graphic display which is easier for customer to operate
|
Applications
•ISP (Internet Service Provider), •IDC (Internet Data Center), •Computer Room, •Small or medium data centers, •Intelligent equipments, •Precision instruments
